Hand-Built Engineered Bellow
Clamp Type Multi Arch – Rubber Expansion Bellow
Multi-arch rubber expansion bellow with sleeve ends that clamp directly over pipes. Widely used on vibrating screens to suppress vibration transfer to adjoining structures and act as a dust-tight enclosure preventing spillage of powders, granules or aggregates.
Technical Specifications
- Multiple arcs for maximum movement compensation
- Sleeve ends clamp directly over pipes
- Fabric reinforcement construction
- SS316 Vacuum Support Rings available
- Used on vibrating screens and bulk material systems
- Acts as a dust-tight enclosure
- Available in Silicon, EPDM, Neoprene, Butyl, Nitrile, Natural and other elastomers
Size: DN 25 to 1200 mm
Let's Build Together.
Have a challenging project? Our engineering team is ready to analyze your requirements and provide custom solutions.
Global Headquarters
SHROFF PROCESS PRODUCTS
Bhartiflex House
Sun Phram - Atladra Road
Vadodara - 390012, Gujarat Bharat
Request Technical Specs
Support
Frequently Asked Questions
Common questions about this product
A multi-arch design has multiple convolutions in the rubber body. This provides greater flexibility and movement absorption.
It is installed using clamps over sleeve ends. This allows simple fixing without conventional flanges.
It is used in ducts, HVAC systems, and low-pressure lines. It is suitable where large movement needs to be absorbed.
Multiple arches allow greater axial and lateral movement. They also reduce stress on connected systems.
Yes, the clamp-type design allows quick removal and replacement. This helps reduce maintenance time.
